Universal Compatibility
Perfect for hot-desking and mixed deployment environments, the universally compatible SD5600T works with Thunderbolt 3 and USB-C laptops running Windows or macOS. Now compatible with Thunderbolt 4 laptops at Thunderbolt 3 features.
Thunderbolt 3 Technology
Allows you to transfer up to 40Gbps of data, video, and audio (10Gbps for USB-C Gen2 laptops, 5Gbps for USB-C Gen1 laptops) using the included 0.8m (2.6 ft.) Thunderbolt 3 cable, for a quick and powerful plug and play experience.
Single 4K or Dual 4K Video Output for Thunderbolt 3 Enabled Devices
Extend visual productivity with the crisp resolution, contrast, and color depth of Ultra HD (Single or Dual 4K @ 60Hz) via two DisplayPort ports. USB-C laptops must support Alt Mode. For USB-C Alt Mode devices, a maximum resolution of Single 4K 60Hz or Dual 1440p @ 30Hz is supported for HBR3 laptops or Single 4K 30Hz or Dual 1080p @ 60Hz is supported for HBR2 laptops (dual monitors are for devices that support MST). M1/M2 Base Chipset MacBook supports only a single external display.
Supports USB-C PD 3.0 up to 100W (96W certified)
Quickly and simply charge any Thunderbolt 3 or USB-C enabled laptop. USB-C laptops must support Power Delivery. Ideal for devices that require higher power, such as the newer MacBook Pro. Power delivery rates vary based on host device.
Productive Desktop Setup
This 15-port universal docking station provides plenty of ports for all your needs: One front USB-C Gen2 port (up to 10Gbps with 5V/1.5A charging), six USB-A ports (1 front Gen2@10Gbps front with 5V/1.5A charging, 5 rear Gen1@5Gbps, 5V/0.9A), one Gigabit Ethernet port, and one audio combo jack.
Built-in SD and Micro SD Card Readers
UHS II SD 4.0 card readers enable ultra-fast file transfer.
Product Specifications
- Connection Technology:
- Thunderbolt 3 & USB-C (Cross Platform Compatibility)
- Driverless:
- Yes
- Additional Screen Outputs:
- 2
- Video Ports:
- DisplayPort, HDMI
- Maximum Resolution:
- 4K
- Power Delivery :
- 96W
- Operating System(s):
- macOS, Windows
- SD Card Reader:
- Yes
- Number of USB Ports:
- 7
- USB Fast Charging:
- Yes
- TAA Compliant:
- No
- Docking Station Family:
- The Innovator
- DockWorks:
- Yes
- Best For:
- Thunderbolt 3 and USB-C Laptops and Monitors that support up to dual 4K
- Compatibility:
- macOS 10.14 or above, Windows 10 or above
- Card Reader:
- SD Cards and Micro SD card slots (UHS-II, SD4.0)
- USB-A Ports:
- 6 x: (1) USB-A 3.2 Gen2 (front) with 5V/1.5A fast-charging & (5) USB-A 3.2 Gen1 (back) supporting 5V/0.9A
- USB-C Ports:
- 1 x USB-C 3.2 Gen2 (front) with 5V/1.5A charging
- Audio:
- 1 x 3.5mm Combo Microphone & Headphone Port (front)
- Data Transfer Speeds:
- Supports up to 40Gbps data transfer speed
- Ethernet Speed (Mbps):
- 10, 100, 1000
- Maximum Resolution Supported:
- Thunderbolt 3 -Single or Dual Monitors: 4K (3840 x 2160 @ 60Hz) // USB-C Alt Mode HBR3 -Single Monitor: 4K @ 60Hz or Dual Monitors: 1440p @ 60Hz
- Mounting Option:
- Maximize desktop space and reduce desktop cable clutter via our optional Docking Station Mounting Bracket (K34050WW)
- Warranty:
- 3 years
- Plug & Play:
- Plug & Play installation without need for drivers or downloads
- Security Slot Compatibility:
- Kensington Nano Security Slot, Kensington Security Slot
- System Requirements:
- Compatible with laptops equipped with Thunderbolt 3 and USB-C ports supporting Alt Mode. Supports up to 40Gbps total bandwidth for Thunderbolt 3 laptops and up to 10Gbps for USB-C laptops.
- USB-C Power Delivery:
- Supports USB-C PD 3.0 up to 100W (96W certified)
- Video Output:
- 2 x DisplayPort v1.2, 2 x HDMI v2.0
- 4K Support:
- Yes
- Packaging Type:
- Retail
